1080p60 PTZ Camera with USB 3.0, HDMI Out, Auto Framing & Presenter Tracking – CAM-210-PTZ

Part of the Unified Communication line of products, the CAM-210-PTZ offers a premium video conferencing experience. HD 1080p video ensures users appear crystal clear in their meetings. A high-quality pan and tilt motor provides a smooth experience without excess noise or judder. Equipped with three outputs, the CAM-210-PTZ can output video via its USB 3.0 port, HDMI port or the network connection. 3rd-party control is a breeze by utilizing the industry standard VISCA protocol. An integrated web interface and free PC software provide advanced configuration options.

Specifications
AUDIO & VIDEO
Outputs:
1x USB 3.0 Type B female
1x 8-pin RJ-45 Female
1x HDMI female Type A

Video Resolution (Max):
USB 3.0 1920x1080p @30Hz
2m (passive cable)
15m (with CAB-UAOC-15)
Cat5e or Higher 1920x1080p @30Hz
100m/328ft

Output Video Encoding:
USB 3.0 MJPEG/YUY2 | UVC 1.5
Network H.265/MJPEG | CBR or VBR up to 2Mbps

CAMERA & SENSOR
Sensor: 1/2.7inch, 2.07M CMOS sensor

Lens: 12x, f=3.5mm ~ 42.3mm, F1.8 ~ F2.8

Zoom: Optical: 12x | Digital: 16x

Shutter: 1/30s ~ 1/10000s

White Balance: Auto, Indoor, Outdoor, One push, Manual, VAR

Minimum Illumination: 0.5Lux @ (1.8, AGC ON)

Backlight Compensation: Supported

Digital Noise Reduction: 2D & 3D DNR | Signal Noise Ratio: ≥55dB

Viewing Angle: Horizontal: 72.5° | Vertical: 44.8°

Rotation: Horizontal: ±170° | Vertical: 44.8°

Pan Tilt Zoom: Pan: 1.7°~100°/s | Tilt: 1.7°~69.9°/s

Image Flip: Horizontal and vertical supported

COMMUNICATION & CONTROL
IR: Built-in IR receiver

Ethernet: 1x 8-pin RJ-45 Female

RS-232: 1x 8-pin Mini Din (max length 30m)

POWER
Power Supply: 12V DC 1A

Max Power Consumption: 18W
