4K60 8×8 HDBaseT™ Matrix – MXV-0808-H2A v3

Offering transmission of 18Gbps HDMI content up to 35m/115ft by pairing HDBaseT with WyreStorm’s powerful lossless compression algorithm, the MXV-0808-H2A brings the familiar power of the WyreStorm H2-series to a compact 1U chassis. Unlike competing compression methods such as CSC, which permanently remove color data, WyreStorm’s VLC uses lossless compression technology to ensure signal integrity.

With 8 HDBaseT zone outputs and 4 mirrored HDMI outputs–which can be paired with WyreStorm’s hybrid HDMI cables or any extender–and CEC triggering for all 12 connected screens, the MXV-0808-H2A enhances the offering for the modern home or commercial installation.

Specifications
AUDIO & VIDEO
Inputs: 8x HDMI In: 19-pin type A

Outputs:
8x HDBT Out: 8-pin RJ-45 Female
8x S/PDIF Out: TOSLINK (Digital Optical)
4x HDMI Out: 19-pin type A

Video Encoding: HDBaseT™ Class B

Encoding Data Rate: 9.2Gbps

Audio Formats:
Analog: 2ch Analog
S/PDIF: 2ch LPCM | Dolby Digital/DTS up to 5.1ch
HDMI: 2ch LPCM | Multichannel up to Dolby Atmos and DTS-X

Video Resolution (Max):
1920x1080p @120Hz 12bit
3840x2160p @60Hz 10bit 4:2:0 HDR
4096x2160p @60Hz 8bit 4:4:4

Supported Standards: DCI | RGB | HDR | HDR10 | Dolby Vision up to 30Hz | HLG | BT.2020 | BT.2100

Maximum Pixel Clock: HDMI: 600MHz | HDBaseT: 297MHz

COMMUNICATION & CONTROL
HDMI: HDMI 2.0 | HDCP 2.2 | EDID | CEC | DVI/D supported with adapter (not included)

HDBaseT: HDMI 2.0 | HDCP 2.2 | EDID | 1-way PoH | Bidirectional IR

CEC: Custom and standard CEC power triggering via API | Requires CEC compatibility | HDMI outputs only

IR: 8x IR RX: 3.5mm (1/8in) TRS Stereo | 8x IR TX: 3.5mm (1/8in) TS Mono | Bidirectional over HDBaseT

RS-232: 1x RS-232: 9-pin DB9 Female | Routable RS-232 Device Control

Ethernet: 1x LAN: 8-pin RJ-45 Female

POWER
Power Supply: 100~240V AC 50/60Hz

Max Power Consumption: 168W
