– DGS-1100-05

Powerful and flexible networking solution for small, medium, and enterprise businesses.

• 5 x 10/100/1000BASE-T ports
• Compact design for convenient placement
• Fanless design for silent operation
• Innovative D-Link Green energy saving features
• Complete web interface for comprehensive switch management

Specifications
Head-of-line (HOL) Blocking Prevention: Yes
Store-and-Forwarding: Yes
Comply with RoHS 6: Yes
1000Base-T Interface: 5
10/100/1000BASE-T ports: 5
CPU Speed: 62.5 MHz
DRAM Size: 48K Bytes
Flash Memory Size: 2 MB
FAN: Fanless
Packet Buffer Size: 1 Mbits
Jumbo Frame: 9216 bytes
Loopback Detection (LBD): Yes
MAC Address Table Size: 2112
Web-based GUI: Yes
D-Link Network Assistant: Yes
Port Mirroring: Yes
Switch Capacity: 10 Gbps
Max. Packet Forwarding Rate: 7.44 Mpps
Power Input: AC：100 ~ 240 V (5V/1A power adapter)
Maximum Heat Dissipation: 11.67 BTU/hr
Dimension: 100.5 × 82 × 28 mm
Maximum Power Consumption: 3.42 W
MTBF: 1,562,055 hours
Operating Altitude: 2000m
Operation Humidity: 0% ~ 90% RH
Operation Temperature: 0 ~ 40 °C
Standby Power Consumption: 1.39 W
Storage Humidity: 0% ~ 95% RH
Storage Temperature: – 40 ~ 70 °C
Weight: 0.23 kg
