– DGS-3130-54PS

The DGS-3130 Series is a highly versatile Lite Layer 3 stackable switch. It has powerful L2 & L3 features as well as support for multiple software images. It is extremely flexible, capable of accommodating different network deployments.

• 48 x 10/100/1000BASE-T PoE ports
• 2 x 10GBASE-T and 4 x 10G SFP+ ports provide all the uplink capacity your network needs
• Premium L2 and L3 features effortlessly improve network efficiency and reduce unnecessary data transfer
• High redundancy features to provide professional-grade reliability and a longer product life:
— Dual power inputs
— Ethernet Ring Protection Switching with <50ms recovery time — 6 kV surge protection protects the device and those connected from unexpected surges — 802.1d/w/s Spanning Tree Protocol avoids potentially network crippling loops • RIP/RIPng and OSFPv2/v3 dynamically maps out your network, aiding data to get to its destination via the fastest route possible. • A formidable PoE budget of 370 W allows powering of numerous external devices (further expandable to 740 W) • Expand capacity in a flash with physical stacking up to 9 units • 80 Gbps per device physical stacking bandwidth • The Smart fan self-adjusts accordingly to maintain optimal operating temperatures Specifications 10/100/1000BASE-T PoE ports: 48 1000Base-T PoE Interface: 48 10G SFP+ Interface: 4 10GBase-T Interface: 2 Console Port: 1 10GBASE-T ports: 2 10G SFP+ ports: 4 RJ-45 Console port: 1 RJ-45 Management Port: 1 USB 2.0 port: 1 USB Port: 1 Switch Capacity: 216 Gbps Max. Packet Forwarding Rate: 161 Mpps Store & Forwarding Forwading :Yes Control Module Redundancy: Yes Dimension: 440(W) x 44(H) x 350(D) mm Weight: 5.14Kg Operation Temperature: 0 ~ 50 °C Storage Temperature: - 40 ~ 70 °C Operation Humidity: 10% ~ 90% RH Storage Humidity: 5% ~ 90% RH Operating Altitude: 2000m Maximum Power Consumption: 487.26 W (with 370 W PoE load) 907.71 W (with 740 W PoE load) Standby Power Consumption: 67.96W Maximum Heat Dissipation: 1662.6 BTU/h (with 370 W PoE load) 3097.24 BTU/h (with 740 W PoE load) MTBF: 356,876 hours Power Input: AC：100 ~ 240 V Redundant Power Supply: DPS-700 CPU Speed: 1.25GHz DRAM Size: 1GB DDR4 Flash Memory Size: 256MB NAND Packet Buffer Size: 4MB FAN: Yes Comply with RoHS 6: Yes
